Macchina riempitrice e tappatrice per sacchetti con beccuccio ad alta velocità CB-8HXZ

Descrizione

The Fully Automatic High-Speed Spout Pouch Filling and Capping Machine is an advanced solution independently developed, designed, and produced by our company. This next-generation equipment is ideal for automatic filling and capping of spout pouches and stand-up pouches, serving industries such as food, cosmetici, automotive products, e altro ancora. The complete line encompasses pouch feeding, material loading, Riempimento, cap placement, and capping processes. It is characterized by stable production, high speed, and versatility, with mold changes allowing the use of different pouch sizes.

Caratteristiche eccezionali

• Rotary Drive System: Proprietary servo-driven rotary indexer, offering a compact, lightweight structure with easy installation and adjustable angles. The built-in auto-reset ensures high-speed operation and user-friendly functionality compared to traditional cam systems.
• Precision Filling Mechanism: Equipped with a full servo-driven magnetic gear pump for high-precision, limitless volume filling of various liquids and pastes. Our independently developed high-pressure filling heads ensure drip-free and backflow-free operation. The filling hopper features automatic level detection and refill capabilities, enabling unmanned, efficient operation.
• Servo-Controlled Capping System: Features an independent servo-controlled capping mechanism, with capping heads processed by advanced wire-cutting technology for long-lasting durability and minimized defect rates. The automated cap feeder includes cap detection and replenishment, while our custom-developed quasi-magnetic suspension track ensures seamless cap feeding. The system alerts users when caps are missing, maximizing efficiency.
• Automatic Bag Feeding Option: The machine can be equipped with an auto bag feeder, supporting automatic bag loading and detection.
• Hygienic Construction: Constructed with 304 food-grade stainless steel and 316 stainless steel for material contact areas, ensuring rust resistance and high sanitary standards. Additional options for the food industry include an automatic high-temperature water cleaning system, a GMP-grade laminar flow hood for dust removal, and nitrogen flushing for product preservation and sterilization. The design incorporates waterproofing for easy cleaning, meeting stringent GMP hygiene requirements.
