Steel Tube Packing Machine

Description
- Additional cylinder device for auto-feeding
- Bracket for assembly product pre-wrapped and collect finished packaged products
- 3 independent motors (Conveyor, film plastic and end sealing)
- Motion controller for quick response to various commands
- Accurate positioning
- Digital temperature control
- Food grade SUS304 contact parts
- Touch screen 7”
Outstanding Features
- All control in one touch screen, user-friendly and easy operation
- Product cutting prevention, machine will stop once cutter cuts the produc
- Memory function, can store 99 groups of package parameters (product position, packing speed, bag length)
- Block board for separate the finished products into batchs
- Product permit length as long as 6 meters

Get a Free Quote

CB-300SG Air cylinder feeding tube pipe packing machine with finished product collecting bracket

[CHLB machine]Round tube metal pipe automatic feeding packaging machine CB-300SG

[CHLB machine]CB-300SG PVC or metal pipes and tubes packing machine

Specification

모델	CB-300SG
Film width	≤300mm
Film thickness	30-80um
Dimension of film bobbin	Outer diameter≤300mm Inner diameter≥75mm
Single knife bag size	엘(60-6000)xW(50-140)xH(3-50)mm
Single knife packing speed	20-200bags/min
힘	220V/380V,50HZ/60HZ,4.65KW
Outer dimension	Accroding to the real product length
Machine weight	1000KG
모터 구성	Full servo
Film bobbin position	Upper
Blade cut type	로타리
Fix device	Air cylinder auto feeder Finished product collecting bracket

산업

Deliver the right machine for your project. Our equipment is suitable for a wide range of industries and applications. Customize a machine for your business.
